Wareshare Flame Sensor

Wareshare

Wareshare Flame Sensor

Rs. 581.00

Shipping calculated at checkout.

Quantity

📦 Description

Overview
1. Sensitive to flame spectrum
2. Features wide range voltage comparator LM393
3. Adjustable sensitivity
4. Signal output indicator

Specifications
1. Spectrum range: 760nm ~ 1100nm
2. Detection angle: 0 - 60 degree
3. Power: 3.3V ~ 5.3V
4. Operating temperature: -25 ~ 85 degree C
5. Dimension: 27.3mm * 15.4mm
6. Mounting holes size: 2.0mm

Applications
1. Fire detection
2. Fire fighting robot
3. Fire alarm


Specification:
Package Weight
One Package Weight 0.01kgs / 0.02lb
One Package Size 5cm * 3cm * 1cm / 1.97inch * 1.18inch * 0.39inch
Qty per Carton 6240
Carton Weight 15.00kgs / 33.07lb
Carton Size 60cm * 39cm * 40cm / 23.62inch * 15.35inch * 15.75inch
Loading Container 20GP: 284 cartons * 6240 pcs = 1772160 pcs
40HQ: 661 cartons * 6240 pcs = 4124640 pcs
